| Place of Origin: | CHINA |
| 브랜드 이름: | IKP |
| 인증: | CE/UL/REACH/ROHS |
| Model Number: | Toroidal Transformer |
| Minimum Order Quantity: | 1000 |
|---|---|
| 가격: | 3.00-20.00 |
| Packaging Details: | Carton |
| Delivery Time: | 10-15 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100,000/week |
Specifications:
• Power range:30VA to 1000VA
• Input / Output: Customized
• Insulation Class: UL class B, F, H, N (optional)
• Isolation: 4KV (Hi-pot)
• Easy to change diameter and height of the core
• Customized specifications are welcome
|
Rated Power (VA) |
Outside Dimension D*H(mm) |
Weight (kg) |
Temp. Rise (℃) |
Approval |
| 30 | 80*32 | 0.54 | 30 | UL/CE/RoHS/CQC |
| 50 | 90*33 | 0.78 | 45 | UL/CE/RoHS/CQC |
| 60 | 100*33 | 0.94 | 47 | UL/CE/RoHS/CQC |
| 80 | 105*34 | 1.11 | 50 | UL/CE/RoHS/CQC |
| 100 | 110*35 | 1.29 | 51 | UL/CE/RoHS/CQC |
| 120 | 115*35 | 1.48 | 52 | UL/CE/RoHS/CQC |
| 250 | 135*42 | 2.57 | 53 | UL/CE/RoHS/CQC |
| 300 | 152*44 | 3.28 | 54 | UL/CE/RoHS/CQC |
| 400 | 153*50 | 3.87 | 54 | UL/CE/RoHS/CQC |
| 500 | 160*55 | 4.65 | 55 | UL/CE/RoHS/CQC |
| 600 | 175*57 | 5.63 | 56 | UL/CE/RoHS/CQC |
| 800 | 191*62 | 7.05 | 57 | UL/CE/RoHS/CQC |
| 1000 | 192*70 | 8.00 | 58 | UL/CE/RoHS/CQC |
◆We can design and manufacture customized part with specific requirement◆We can design and manufacture customized part with specific requirement
